3.4 Inch Round TFT Display, With Touch Panel 800x800 MIPI Interface 380 CD/M2

Ask Latest Price
Video Channel
Brand Name :HuaXin
Model Number :ESHX340CIC10B
Certification :ISO14001/ ISO9001/IATF16949
Place of Origin :China
MOQ :1000pcs
Price :negotiation
Payment Terms :T/T
Supply Ability :100K per month
Delivery Time :6weeks~8weeks
Packaging Details :blister+foam box+bubble bag+inside carton+master carton
Display Technology :touch screen TFT
name :Round TFT module
size :3.4 "
resolution :800x800
Brightness :380cd/m2
drive IC :ILI9881C
view angle :Free
interface :MIPI
more
Contact Now

Add to Cart

Find Similar Videos
5 Inch Round LCD Display,  1080x1080 50 Pins MIPI Interface 350CD/M2 00:20
5 Inch Round LCD Display, 1080x1080 50 Pins MIPI Interface 350CD/M2
2.1 Inch TFT Round Display Knob Screen With Linux System 480x480 Resolution RGB Interface 01:30
2.1 Inch TFT Round Display Knob Screen With Linux System 480x480 Resolution RGB Interface
2.85 inch TFT round display module,480*480 dots  RGB+MIPI interface driving IC ST7701S 00:13
2.85 inch TFT round display module,480*480 dots RGB+MIPI interface driving IC ST7701S
0.75 inch TFT round display module 160*160 dots  4SPI/18BIT interface driving IC GC9D01N 00:17
0.75 inch TFT round display module 160*160 dots 4SPI/18BIT interface driving IC GC9D01N
TFT Display Module 1.85 Inch With Touch Panel 360*360 Resolution 450nits QSPI Interface 00:15
TFT Display Module 1.85 Inch With Touch Panel 360*360 Resolution 450nits QSPI Interface
2.1 Inch Round TFT Display 480x480 250cd/M2 40 PINS 18bit RGB Interface 00:27
2.1 Inch Round TFT Display 480x480 250cd/M2 40 PINS 18bit RGB Interface
1.5 Inch Circular TFT Display , 320x320 24PINS MIPI,  350cd/M2 Circle LCD Display 00:15
1.5 Inch Circular TFT Display , 320x320 24PINS MIPI, 350cd/M2 Circle LCD Display
2.4 Inch TFT LCD Display Module 320x320 Resolution 300nits MIPI 1LINE 00:28
2.4 Inch TFT LCD Display Module 320x320 Resolution 300nits MIPI 1LINE
3 Inch TFT LCD Display Module 480x480 Resolution 300nits 41pins RGB 24bit +SPI 00:31
3 Inch TFT LCD Display Module 480x480 Resolution 300nits 41pins RGB 24bit +SPI
5 Inch Round Tft Lcd Display,  With HDMI Board 1080x1080 50pins MIPI , Driving IC 350c/D 00:17
5 Inch Round Tft Lcd Display, With HDMI Board 1080x1080 50pins MIPI , Driving IC 350c/D
View Product Description

ESHX340CIC10B is 3.4 inch round TFT display with touch panel ,800x800 Resolution, 39 pins MIPI interface, brightness is 380 cd/M2 TFT lcd and lcd display Driver IC is ILI9881C and CTP IC is HX8526.View angle is free

A: Product Parameter

ITEM specification
Model Number ESHX340CIC10B
size 3.4inch round tft
LCD Type IPS
Number of pixels 800x800
Active area 87.6x87.6mm
OutlineSize(W*H*T) 99x96.6x3.98mm
Viewing direction free view angle
LCM Driver IC ILI9881C
LCM interface MIPI
PIN number 39pins
LED number 6pcs
operating temperature -20~70
storage temperature -30 to +80
Luminance 380c/d
touch panel CTP

B:Product Picture

3.4 Inch Round TFT Display,  With Touch Panel 800x800 MIPI Interface 380 CD/M2

3.4 Inch Round TFT Display,  With Touch Panel 800x800 MIPI Interface 380 CD/M2

3.4 Inch Round TFT Display,  With Touch Panel 800x800 MIPI Interface 380 CD/M2
C: Drawing

3.4 Inch Round TFT Display,  With Touch Panel 800x800 MIPI Interface 380 CD/M2

3.4 Inch Round TFT Display,  With Touch Panel 800x800 MIPI Interface 380 CD/M2

3.4 Inch Round TFT Display,  With Touch Panel 800x800 MIPI Interface 380 CD/M2
D: TFT Product Knowledge

tft substrate input and CF substrate input flow chart as below

3.4 Inch Round TFT Display,  With Touch Panel 800x800 MIPI Interface 380 CD/M2

TFT structure as below

3.4 Inch Round TFT Display,  With Touch Panel 800x800 MIPI Interface 380 CD/M2


E: Company Information

Huaxin Advantage:
1. factory base located at inland city which has cost effective
2. most advanced new equipment which can keep quality stable
3. most processes using fully automatic equipment which has effeciency and stable quality
4. professional engineers and production leaders who works in lcd field for more than 20 years
5. self design for customized product

our certificates
1.ISO14001/
2.ISO9001/IATF16949
3.SGS of LCD module

  • Huaxin Technology (Enshi)Co.,LTD
  • Hubei.Enshi
  • Date of foundation:2009
  • high technology enterprise mainly work on research and development, producing and sells LCD,LCM,TFT,backlight,OLED
  • LCD includes: VA,TN, HTN, STN, FSTN, CSTN and other series
  • LCM includes: COB,TBA, COG,TP,LED backlight and other series
  • register capital:twenty million
  • current staff:500+
  • RD accounts for 10%
  • QC accounts for 15%

F: Production Capacity

Annual Production
Capacity
2021 (Current) 2022 (Goal) 2023 (Challenge) 2024 (Challenge) 2025 (Challenge) Remark
LCD Producton
Capacity
4.5 9 9 9 9 Unit:thousands of
logarithms/Day
LCM Producton
Capacity
70 150 300 450 450 Unit:Thousand
piece/Day
Backlight Producton
Capacity
100 200 300 500 500 Unit:Thousand
piece/Day
OLED Producton
Capacity
10 20 30 40 50 Unit:Thousand
piece/Day

G: Product Application

1. car navigation&printer

2. video call & advertising

3.Automotive &medical devices

4.fitness equipment&handheld devices

5.industial control and home applicance

H: TFT Display Characteristics

1.Image Quality: TFT displays offer excellent image quality with high resolution, sharpness, and color accuracy.

2.Response Time: TFT displays have fast response times, which means they can quickly switch pixels on and off.

3.Viewing Angles: TFT displays typically provide wide viewing angles, allowing the screen to be viewed clearly from different positions and angles without significant color shifts or loss of image quality.

4.Energy Efficiency: TFT displays are energy-efficient compared to other display technologies.

5.Size and Flexibility: TFT displays can be manufactured in various sizes, ranging from small screens for handheld devices to large panels for TVs and monitors.

6.Backlighting: Most TFT displays require a backlighting system, such as LED (Light-Emitting Diode) backlighting, to illuminate the screen.

7.Wide Applications:

I: Are there any drawbacks or limitations to using TFT displays?

1. Limited Viewing Angles:

2. Limited Contrast Ratio

3. Backlighting and Power Consumption

4. Response Time and Motion Blur

5. Limited Flexibility

6. Limited Color Gamut
